WL-HMI1001-Lite-4G Gateway-modbus-data collector
Temperature: -20~+70°C (working) 40 ~ +85°C (storage and transportation)
TECHNICAL SPECIFICATION
| Moodle | HMI1001-Lite-4G |
| Supported ports | 1 Ethernet port, 1 RS485 serial port, |
| power supply | AC/DC12~24V |
| Material | Galvanized Steel |
| Humidity | 20%~90% no condensation (working)15%~95% no condensation (storage andtransportation) |
| Os | Linux |
| CPU | 1 Core 750MHz |
| RAM | 64M |
| Flash | 32M |
| Ethernet Ports | 1x 10M/100M NIC |
| Serial Ports | 1x RS485(Electromagnetic isolation) |
| SIM Card Slot | 1x SIM card slot, 4G Unlocked for ALL Carriers |
